It works on principle of baking while stirring. One Agitator arm continuously turn, twist, shake & bake material in one direction in bowl. Jackets on bowl for maximum utilization of fuel. It will bake the material evenly. It has tilting mechanism to unload material. It can be used as a mixing machine to mix materials, slurry or liquids. Useful to heat liquids, semi-liquids & solid materials.
Automatic Roaster Machine
Feature
- p to bottom S.S.304/anodized parts
- Inbuilt High Capacity Gas Burner with flow control
- Machine can be tilted easily for removing material
- Easy locking mechanism for kadai while tilting
- Inbuilt Ac Drive for controlling the rotation speed
- Castor-mounted for easy movement
Used for Making
Specifications |
|
| Machine Body : | SS 304 |
| Machine Dimension : | Length : 198 cm, Width : 106 cm, Height : 127 cm |
| Bowl Diameter : | 39 Inch |
| Bowl Depth : | 14 Inch |
| Bowl Thickness : | 8 mm |
| Bowl Capacity : | 200 Litre |
| Net weight : | 350 KG |
| Machine Connection : | Electric & LPG & PNG |
| Electric Motor : | Bonfiglioli |
| Electric Motor ( HP) : | 2 |
| Gear Box : | Bonfiglioli |
| Driven Type : | Double Gear |
| Drive : | VFD Drive Made by Janpan |
| HMI/PLC : | Delta |
| Electric Wire: | RR Cable or Polycab |
| Auto Ignition System: | Yes |
| Blade Cover Material : | PTFE Food Grade |
| Electricity Power : | 220v AC Single Phase 50 hz 1.5 kW |
| Machine Movable : | Yes ( 4 Inch Castor Wheel ) |
